DIN 5417 External Snap Rings
DIN 5417 External Snap Rings for rolling bearings, SP30-SP300， made of spring steel , phosphated from China snap rings manufacturer.
Standard: DIN 5417
Size: SP30-SP300
Material: Spring Steel
Finish: Phosphated
 |
 |
DIN 5417 External Snap Rings, SP series size chart:
| 30X1.12 | 55X1.12 | 90X2.46 | 150X2.82 | 240X3.5 | 360X4.5 |
| 32X1.12 | 56X1.12 | 95X2.46 | 160X2.82 | 250X3.5 | 370X4.5 |
| 35X1.12 | 58X1.12 | 100X2.46 | 170X3.1 | 260X3.5 | 380X4.5 |
| 37X1.12 | 62X1.7 | 110X2.46 | 180X3.1 | 270X3.5 | 400X4.5 |
| 40X1.12 | 65X1.7 | 115X2.46 | 190X3.1 | 280X3.5 | |
| 42X1.12 | 68X1.7 | 120X1.82 | 200X3.1 | 290X3.5 | |
| 44X1.12 | 72X1.7 | 125X2.82 | 210X3.1 | 300X4.5 | |
| 47X1.12 | 75X1.7 | 130X2.82 | 215X3.1 | 310X4.5 | |
| 50X1.12 | 80X1.7 | 140X2.82 | 225X3.5 | 320X4.5 | |
| 52X1.12 | 85X1.7 | 145X2.82 | 230X3.5 | 340X4.5 |
