DIN 916 Cup Point Socket Set Screws

DIN 916 Cup Point Socket Set Screws, M3-M16, made of steel , Class 8.8 / 12.9 from professional set screws manufacturer in China
Standard: DIN 916
Size: M3-M16
Material: Steel;
Surface: Black oxide, Zinc plated

DIN 916 Cup Point Socket Set Screws specification:

Item	Standard	Finish	Grade	Size ( Metric )	Length
Cup Point Socket Set Screws	DIN 916	Black oxide	8.8 / 12.9	M3	3mm-10mm
Cup Point Socket Set Screws	DIN 916	Black oxide	8.8 / 12.9	M4	4mm-16mm
Cup Point Socket Set Screws	DIN 916	Black oxide	8.8 / 12.9	M5	5mm-20mm
Cup Point Socket Set Screws	DIN 916	Black oxide	8.8 / 12.9	M6	6mm-20mm
Cup Point Socket Set Screws	DIN 916	Black oxide	8.8 / 12.9	M8	8mm-30mm
Cup Point Socket Set Screws	DIN 916	Black oxide	8.8 / 12.9	M10	10mm-50mm
Cup Point Socket Set Screws	DIN 916	Black oxide	8.8 / 12.9	M12	10mm-50mm
Cup Point Socket Set Screws	DIN 916	Black oxide	8.8 / 12.9	M16	12mm-60mm
